Undercounter Single Zone Wine Cooler
The Caple Undercounter Wine Cooler is a sleek, built-in single-zone cooler, designed to store red, white or sparkling wine. It holds up to 19 × 750 ml bottles and chills them to between 5 °C and 18 °C with a no-frost compressor. Touch-control LEDs, UV-free interior lighting and vibration-free, fan-circulated cooling keep bottles uniformly chilled. The unit runs quietly at 39 dB, features five sliding beech shelves plus a base shelf and a reversible door with a modern black square handle. The cooler’s compact width (29.5 cm) and vent-through-plinth design make it easy to integrate neatly under kitchen counters.
Features:
- Black glass door
- Shelves can accommodate 750ml Bordeaux, Burgundy and Champagne bottles
- No-frost compressor cooling technology maintains a consistent temperature
- Single temperature zone
- Stores either red, white or sparkling wine
- Touch Control and white LED display
- Converts into a can chiller using optional glass shelving
- UV/heat-free white LED lighting (switchable)
- Vibration free
- Adjustable height to fit 100-150mm plinth
- Black square handle
- Fan circulated cool air for even temperature distribution
- Reversible door
- Beech shelves
- 1 base shelf
- 5 Sliding shelves
- 100% CFC/HFC free
- Toughened UV protected glass door
- 1 Humidity control water tank
- Black cabinet interior and exterior
- Recessed for fitting furniture plinth
- Air ventilation through plinth grille
- Supplied with a black steel universal plinth grille w:230mm
Specifications
Dimensions:
- Width 295mm
Performance:
- Energy class F
- Noise class C
- Energy consumption 98kWh/yr
- Ambient temperature 16ºC-32ºC
- Temperature range 5ºC-18ºC
- Humidity range >65%RH
- Quiet operation 39dB[A]
Capacity:
- Stores maximum bottles: 19 Bordeaux wine bottles 750ml
Manual
Click here for Instruction Manual
Click here for Installation Diagram
